App Printing & HTML Templates

The platform allows you to print data from any form submission to any printer that is configured and connected to your device. The printer could be connected to your device through Bluetooth, a local network connection, or the Internet.

This is useful when you need to print a receipt, a label, or a report while out in the field, even offline. The layout and formatting of the printed output are controlled exclusively through HTML. You use the standard Data Template syntax in your HTML to inject Form entry answers and other dynamic values.

You can enable this feature by populating the HTML Template property in the App Printing area on the Settings page of a Data Entry Form.

Once populated, form entries can be printed from the app in the following ways:

Via the ‘Upload and Print’ button that automatically appears on a Form’s app submission page with an HTML template defined.
A ‘Print’ button is available when reviewing a completed Form entry in the app History area.
From an ‘Upload Form and Print’ user interaction configured on Action button fields or a Process Field type.

On the web portal, entries can also be printed when viewing them in the Data Entries area after uploading.

Image Support

HTML <img> tags are supported to render images into your template. We keep adding any images/sketches/signatures captured in your form and the company letterhead configured on the Organisation Setup page.

We also support embedding base64 encoded images, should you need to use images other than those mentioned above, while ensuring this feature can be used offline.

You can specify exact dimensions for your images by using CSS, for example:

<img src="imagegoeshere*" style="width:200px; max-width:400px; height:150px; max-height: 300px;"/>

We do not recommend using URLs to images on the internet, as this will not work when the app is offline.

Below are a few examples of adding images from different sources to your template:

Organisation Letterhead Example

The organization letterhead image can be accessed simply by using the ORGLETTERHEAD built-in as the value of the src attribute.

Form Entry Image Example

You need to use the FILEURL formula for images captured in your form. You must also wrap the formula in {( and )} characters to indicate that it’s a formula and not plain text. {{dataname}} in the example below refers to the dataname of an image or sketch field within your form.

<img src="{( FILEURL( {{dataname}} ) )}"/>

Base64 Embedded Image Example

Base64 encoding is an encoding scheme that allows you to store data (in this case, image data) in text format. This will enable you to embed any image into your template without an active internet connection.

You can convert images to base64 encoding using one of the many online tools available (such as https://www.base64-image.de/).


Repeats and Optional Sections

The use of {{!REPEATSTART}} and {{!REPEATEND}} is supported, as well as {{!HIDEIFSTART(condition)}} and {{!HIDEIFEND}} placeholders in your template to render repeating sections and show/hide sections of the output based on Form Entry fields and Formulae.
We do not, however, support the use of {{!REPEATROW}} and {{!HIDEROWIF}} placeholders.

For Example:

{{!HIDEIFSTART( COUNT({{repeatPage}}) = 0) }}
{{!REPEATSTART}}
{{repeatField}}
{{!REPEATEND}}
{{!HIDEIFEND}}

App Printing Sample

When logged into your account’s web portal, you can find and install a simple-to-use Examples Catalog App, “App Printing Sample,” that showcases the abovementioned functionality.

Once installed, navigate to the form’s Settings to view the HTML Template and how it correlates to its design. Then, jump into the app and test it out.

In-app and device process outlined:

Fill out the form
Upload & Print
Choose a configured printer (device options). If your device has no printer configured, it should prompt you to save as a PDF.
